General
Max Printing Speed1 1200mm/s
Max Acceleration2 40000mm/s2
Peak Flow Rate3 110mm3/s @FLSUN PLA-HS
Build Volume5 Φ320mm*430mm
(maximum height of the cylinder: 383mm)
Chamber Closed
Tool Head
Nozzle 0.4mm Hardened Steel Nozzle
Max Hot End Temp. 350℃
Filament Diameter 1.75mm
Heatbed
Build Plate Textured PEI Plate
Max Build Plate Temp. 120℃
Smart Zone Heating Inner Circle Φ220mm, Outer Ring 220-320mm
Features
Monitoring Camera Realtime, Timelapse
Filament Detection Yes
Filament Clog Detection Yes
Vibration Compensation Yes
Debris Detection Yes
Spaghetti Detection Yes
Screen Auto Sleep Yes
Printer Auto Power Off Yes
Smart Zone Heating Yes
Auto-Leveling Yes
Power Loss Recover Yes (Z lift, Backup Battery)
Air Filter HEPA + Activated Carbon
Electronics
Display 7” Color Touch Screen
Storage 16GB EMMC、32GB USB Flash
Power Supply 110-240V, 50/60HZ
Physical Dimension 550*595*1030mm
Net Weight 41kg
Software
Firmware Upgrade OTA
Slicing Software FLSUN Slicer V2.0、Other Slicers
Slicer Supported OS MacOS, Windows
Formats for Slicing STL, OBJ, AMF, 3MF
Filament
Supported Filament Ideal: PLA、 PETG、 TPU
Satisfactory: ABS、 ASA、PA、 PC、PET
Capable: Carbon/Glass Fiber Reinforced PLA
Active Heating Dry Box Yes

Note:

1. The maximum printing speed refers to peak instantaneous speed. Actual speed is adaptive based on printing algorithms and may vary depending on parameters, model, slicing software, and environment.
2. Maximum toolhead acceleration refers to peak instantaneous acceleration. Actual acceleration adapts automatically and may vary due to parameters, model, slicing software, and environment.
3. Peak flow indicates instantaneous flow rate. Actual flow adapts automatically and may vary with parameters, model, slicing software, and environment.
4. Data is collected by FLSUN under consistent environmental and printing parameters.
5. Maximum build height applies to the center point; height limit decreases gradually from center to edges, reaching 383mm at the outermost edges.
6. Decibel level data is collected in an enclosed chamber, one meter from the printer. Actual noise level may vary with ambient noise, room dimensions, surrounding surfaces, and atmospheric conditions.
7. Availability of FLSUN World features may vary depending on the region/country, OS version. The features described on the page may not be included in the software version at launch, they wilI be updated via OTA.

* Product images are for reference only. Specifications and descriptions may change due to supplier or manufacturer updates. Data is based on FLSUN technical parameters and laboratory tests, and may vary slightly depending on testing environment, software version, and specific model version.
